Prefabricated Steel Truss Pedestrian Bridge Design Bailey Bridge Structures

China supplier Top quality galvanized pedestrian truss bridge steel structures bailey bridge

Product Description

Bailey bridge is used when there is a need to cross an obstacle for a certain time period.This is often in case of military operations, during or after natural disasters replacement or renovation of consistent bridges or in unusually areas like the movie industry. Thereby the function also differs on differs on different users of the bridge which could be pedestrians, common vehicles(cars,busses,trucks),heavy military equipment (tank) or the railway.

Specification

Features:

1. Speed construction- pre-engineered components

2. Easy - to handle, transport, assemble, install and reuse

3. Cost effective to own and re-use in different length bridges

4. Damaged parts can be easily and quickly replaced from stock

5. Made of steel with hardwoord for decking

6. All steel is precision CNC machined and laser cut components

7. Faithfully replicates the key component of the original Bailey Bridge, including the Panels, Transoms, Stringers,

Chesses, Ribands, Rakers, Bracing Frames, End Posts and Sway Braces.

8. Additional sections can be added to increase the length of the bridge

9. Additional panels can be added to create Double and Triple panel bridges.

10. Includes all fasteners, pins and bearings

11. Simple exploded view instructions

12. Sections can easily be separated for transport

1) Material grade

1. Carbon structural steel: Q235; High-strength structural steel: Q355

2. Special purpose steel

2) Quality standard

1. Certificate: ISO9001:2000

2. Code for design of steel structure: GB 50017-2003

3. Technical code of cold-formed thin-wall steel structure: GB50018-2002

4. Load code for the design of building structures. GB 50009-2006

5. Construction quality acceptance of steel: GB50205-2001

6. Code for design, construction and acceptance of high strength for steel structure, JGJ82-2011

7. Technical specification for welding of steel structure building: JGJ 81-2002

8. Technical specification for steel Structures of tall buildings: (JGJ99-98)

3) Structure assembly

1. Steel framework:

Component: H-Column, H-Beam & C/Z-Purlin

Connection of steel structure method: Welding, bolted

2. Surface treatment: Painting, galvanized

3. Roof &Wall: Colored steel tiles or colored steel sandwich panel as per request

4. Doors: Rolling or pushing, as request

4) Steel characteristics

1. Environmental protection

2. Higher reliability of steel work

3. Strong quake-proof

4. Higher degree of industrialization

5. Quick to be assembled accurately

6. Larger interior space

If you need more product information and quotation,please contact us. Various US America standard, EU Europe Standard, AU Australia New Zealand standard, UK Britain standard etc fabrication are no problem for us. welcome your enquiry and visit.
