Surface Treatment: | Hot Dip Galvanized Or Painted | Material: | Steel |
---|---|---|---|
Cost: | Reasonable | Warranty: | 3 To 50 Years |
Grade: | Q235 Q345 & Q355B Steel | Performance: | Safety, Convenient, Easy To Install Etc. |
Size: | Customized Size | Application: | River, Farm, Highway, Railway, Emergency, Military |
High Light: | Portable Prefabricated Steel Truss Bridge,Compact Steel Truss Bridge,Modular Prefabricated Truss Bridge |
Bailey Bridge is a type of portable, pre-fabricated, truss bridge. It was developed by the British during World War II to provide military access across rivers or other bodies of water. The name comes from its inventor, Donald Bailey, who designed and patented the structure in 1936.
Compact 200 Bailey bridges are developed on the base of compact 100 Bailey bridges providing wider roadway, greater rigidity, greater stability overall, greater fatigue life and more effective structures. With panel height increased to 2.134m, it is an excellent choice for load designs of HS-15, HS-20, HS-25, HL-93 and more.
Specifications:
Single lane | STD Carriageway Net Width: 4.2m | Single span: 18m-67m |
Double lane | STD Carriageway Net Width:7.35m | Single span: 18m-67m |
Bridge deck | Anti-slip steel decking floor,checkered steel plate etc |
Steel grade | Q345B/Q355 (equivalent to ASTM A572) or custom required |
Loading capacity | 20ton, 40ton truck etc, or HS20-44, HS25-44/Truck 20/HL-93 |
Installation of the Steel Bailey Bridge:
Method 1 Craning: use of certain tons capacity crane on site, which allows a quick and easy assembly and installation
Method 2 Launching: When the site does not allow crane to work, the Panel Bridge, which can be carried by manpower, can be assembled manually and installed by launching using a pushing device with a limited capacity.
Advantages:
1.Great stability
2.Single or double lanes are optional
3.Lightweight components
4.Easy to assembly and dismantle
5.Strong environment adaptability.
6.Wide range of applications
Applications:
Infrastructure upgrading
Railway
Highway
Footbridge
Emergency
Military
Residential community
Farms
Rural areas
Temporary
Permanent
FAMOUS runs two well-equipped production bases and the capacity of each one is around 30000-40000tons per year. there are many domestic/overseas projects on the going. In addtion to ISO, we also have the certification of AWS D1.1, AWS D1.5 Bridge field specialized Certification, related tests/inspections have been done .
